VOE11805839 Rockmaster/1SC Volvo escavadeira

VOE11805839 Rockmaster/1SC Volvo escavadeira

Volvo-VOE11805839-aftermarket-wholesale

Click

Click

VOE11805839 Rockmaster/1SC Volvo escavadeira

$1028.00

Select the number of specifications

Please check the product information you want!

Product Details

Volvo EC30(TYPE 282) VOE11805839 Rockmaster/1SC atacado

Nome parte: VOE11805839 Mangueira
KDSORT: 210
UE: U
ANT1: 1
Hose Recipe Asmoverall Length MM: 470
Hose Recipe Asmoverall Length Inch: 18.50
Hose Recipe Asmoverall Length ToL MM: +/- 1%
Hose Recipe Asmoverall Length ToL inch: +/- 1%
Hose Recipe Fitting OrIentationtol Tol Degrees: +/- 3 degrees
Hose Recipe Hydraulic Hose Standard: EN (474-1) (5.18.13 Hydraulic Hosees)
Hose Recipe Safety Standard: EN 982-1996
Hose Recipe Assembly Instruction Reference: 1076838
Hose Recipe Version: 1
Hose Recipe Status: A
Hose Recipe Vendor: MANULI
Hose Recipe Grade: 1
Hose Part Hose Description: Rockmaster/1SC
Hose Part Hose Size DN: 16
Hose Part Hose Size Inch: 5/8"
Hose Part Hose Dash: -10
Hose Part Hose Pressure Class MPA: 15.0
Hose Part Hose Pressure Class PSI: 2175
Hose Part Hose Pressure Class BAR: 150
Hose Part Hose Standard ISO: ISO 11237
Hose Part Hose Standard SAE: Volvo 101
Hose Part Hose Standard EN: EN 857 1SC
Hose Part Hose Standard MSHA: MSHA 2G-IC-126C/8-1
Hose Part Hose Structure: Wire braided one layer
Hose Part Hose Remark: Abrasion, weather and heat resistance
Hose Part Hose Outer Diameter MM: 23
Hose Part Hose Outer Diameter INCH: 0.91
Hose Part Cancelled: N
Hose Part Vendor: MANULI
Hose Part Grade: 1
Hose Part In Program: Y
índice: 10005/911/320, 10006/911/320
Procurar Part NO.VOE11805839(PJ5475012)?
Nós Vender CASE / Komatsu / SUMITOMO / MITSUBISHI / Kubota / HYUNDAI Componentess. Você pode obter esta peça com preço de atacado começando em 1 pcs. Contacte-nos obter o melhor preço.
PJ5475012 substituir Part NO.VOE11805839
VOE11805839 Volvo Circuito hidráulico (arrefecedor de óleo)(1020593 Montagem)
Volvo VOE11805839 Rockmaster/1SC adequada para 1020593 Circuito hidráulico (arrefecedor de óleo) Montagem.
Volvo VOE11805839(c.1020593) Mangueira
Referência: 1020593 / 12 / 1
10006/911/320, 10005/911/320
Válvula de controle VOLVO Atacado CASE / CUMMINS / SAMSUNG / MITSUBISHI / ISUZU / YANMAR Acessórioss. MOQ 1 pcs está disponível! VOLVO Part NO.VOE11805839(PJ5475012) já está à venda!
Part NO. VOE11805839 for Volvo EC30(TYPE 282)
Part NO. VOE11805839 for Volvo EC25(TYPE 281)
VOLVO Construction parts temos nossa própria produção / R & D fábrica, alta qualidade e baixo preço são nossas vantagens.
Com mais de 10 anos de experiência na indústria de máquinas, recebemos elogios de todo o mundo (cliente / revendedor / fabricantes / distribuidores) .
Original VOE11805839(PJ5475012) incluiu fatura normal .
Usado/segunda mão VOE11805839 fornecer garantia de qualidade de 3-12 meses.
Todos os impostos incluídos, sem mais taxas ocultas.
Escolha-nos, obtenha suporte online permanente, o nosso Golden Engineers estão prontos.
