Atacado VOE11806014 Mangueira Volvo escavadeira

Atacado VOE11806014 Mangueira Volvo escavadeira

VOLVO-VOE11806014-aftermarket-wholesale

Click

Click

Atacado VOE11806014 Mangueira Volvo escavadeira

$1028.00

Select the number of specifications

Please check the product information you want!

Product Details

Volvo EC14(TYPE 246, 271) escavadeira Acessórios VOE11806014 Eternity/2

Nome parte: VOE11806014 Mangueira
KDSORT: 140, 250
UE: U
NS_SS: OP
ANT1: 1
ANT2: 1
INFLYTT: 1
GLB_ANM1: 5/16"
Hose Recipe Asmoverall Length MM: 500
Hose Recipe Asmoverall Length Inch: 19.69
Hose Recipe Asmoverall Length ToL MM: +/- 1%
Hose Recipe Asmoverall Length ToL inch: +/- 1%
Hose Recipe Fitting OrIentationtol Tol Degrees: +/- 3 degrees
Hose Recipe Special In Structions: Use two clamps
Hose Recipe Hydraulic Hose Standard: EN (474-1) (5.18.13 Hydraulic Hosees)
Hose Recipe Safety Standard: EN 982-1996
Hose Recipe Assembly Instruction Reference: 1076838
Hose Recipe Version: 2
Hose Recipe Status: A
Hose Recipe Protector Length MM: 445
Hose Recipe Protector Length INCH: 17.52
Hose Recipe Vendor: MANULI
Hose Recipe Grade: 1
Hose Part Hose Description: Eternity/2
Hose Part Hose Size DN: 8
Hose Part Hose Size Inch: 5/16"
Hose Part Hose Dash: -05
Hose Part Hose Pressure Class MPA: 40.0
Hose Part Hose Pressure Class PSI: 5800
Hose Part Hose Pressure Class BAR: 400
Hose Part Hose Standard ISO: ISO 11237 2SC
Hose Part Hose Standard SAE: SAE 100R16
Hose Part Hose Standard EN: EN 857 2SC
Hose Part Hose Standard MSHA: MSHA 2G-IC-126C/8-1
Hose Part Hose Structure: Wire braided two layer
Hose Part Hose Remark: High service life and reliability
Hose Part Hose Outer Diameter MM: 15
Hose Part Hose Outer Diameter INCH: 0.59
Hose Part Cancelled: N
Hose Part Vendor: MANULI
Hose Part Grade: 1
Hose Part In Program: Y
índice: 10003/912/360, 10001/912/710, 10004/912/360, 10002/912/360
Procurar Part NO.VOE11806014(PJ4193122)?
Nós Atacado Hitachi / KATO / Komatsu / HYUNDAI / Kobelco / Kubota Acessórioss. Você pode obter esta peça com preço de atacado começando em 1 pcs. Contacte-nos obter o melhor preço.
PJ4193122 substituir Part NO.VOE11806014
VOE11806014 Volvo(91649X3 Montagem)
Volvo VOE11806014 Eternity/2 adequada para 91649X3 Montagem.
Volvo VOE11806014(c.91649X3) Mangueira
Referência: 91649X3 / 16 / 2
10004/912/360
VOE11806014 Volvo Válvula de segurança (cilindro do braço de afundamento)(E32AQ1 Montagem)
Volvo VOE11806014 Mangueira adequada para E32AQ1 Válvula de segurança (cilindro do braço de afundamento) Montagem.
Volvo VOE11806014(c.E32AQ1) Mangueira
Referência: E32AQ1 / 5 / 2
10001/912/710
VOE11806014 Volvo(91649X1 Montagem)
Volvo VOE11806014 Eternity/2 adequada para 91649X1 Montagem.
Volvo VOE11806014(c.91649X1) Eternity/2
Referência: 91649X1 / 16 / 1
10002/912/360, 10003/912/360
Nós Atacado CUMMINS / SAMSUNG / Hitachi / Caterpillar / SUMITOMO / CASE Acessórioss. MOQ 1 pcs está disponível! VOLVO Part NO.VOE11806014(PJ4193122) já está à venda!
Part NO. VOE11806014 for Volvo EC14(TYPE 246, 271)
Part NO. VOE11806014 for Volvo EC20(TYPE 263 XT/XTV)
Part NO. VOE11806014 for Volvo EC15(TYPE 261 XT/XTV)
Part NO. VOE11806014 for Volvo EC15(TYPE 265 XR)
We temos nossa própria produção / R & D fábrica, alta qualidade e baixo preço são nossas vantagens.
Com mais de 10 anos de experiência na indústria de máquinas, recebemos elogios de todo o mundo (cliente / revendedor / fabricantes / distribuidores) .
Original VOE11806014(PJ4193122) incluiu fatura normal .
Usado/segunda mão VOE11806014 fornecer garantia de qualidade de 3-12 meses.
Todos os impostos incluídos, sem mais taxas ocultas.
Escolha-nos, obtenha suporte online permanente, o nosso Golden Engineers estão prontos.
